Dyehouse

RECIPE CARDS
We use our classic colours every day and often create new shades for special projects. Recipe cards are created and stored for each of the new colours we match and dye.

DYEPOT WITH ECRU YARN
For each dyeing, ecru (undyed) yarn is loaded into the dyepot. All yarn packages are softly wound to allow the dye to be fully absorbed throughout to create an even dyeing. We can dye between 1/2 kilo and 136 kilos per colour.

COLOUR MIXING
Dye powders are mixed to create colours with different ratios of dyes for each shade. This is then mixed with boiling water and fed into the dyepot, where the liquor is pumped through the yarn package via perforated rods.

DYEPOT WITH COLOUR
The process starts at 40 degrees celsius and the temperature increases to around 100 degrees ( boiling point). From loading, dyeing, and rinsing off, the time spent in the dyepot is about 2 hours.

THE WHIZZ
Most of the liquor is drained off in the dyepot and a 5 minute cycle in the Whizz spins off any excess liquid.

DRYING
Yarns can dry for up to 8 hours on racks in our large ovens. The oven temperature is around 80°C.

Yarn Winding

SOFT WINDING
Undyed yarn (ecru) is wound onto a soft package, a metal or plastic spring for the dyeing process. Coloured / dyed yarn needs to be on a firm package such as a cone for the weaving processes.

NAPPING UP
We can join together yarn of the same batch and colour to create packages of larger cones, this is called napping up.

MEASURING LENGTHS
We can wind yarn into specific lengths for larger orders. This is called measured lengths. We can calculate exactly how much yarn we will need to make the job as efficient as possible.

Warping

WARP BANK
Cones of yarn in the colour and sequence of the pattern are mounted on the warp bank.

WARP
Threads are drawn from the bank and wound around the drum to create the length and width of what will become the fabric.

PATTERN
The Threads are are wound onto the drum in the pattern sequence.

BEAMING
When the full width is completed the whole job is wound off the drum onto a beam ready for weaving.

KNOTTING
We knot several jobs of the same quality together to create larger beams for the looms and weaving.

Weaving

WEAVING
Fabric is created by the interlacing of the vertical threads with the horizontal weft threads.

WARP
Warp is held on a beam at the back of the loom. The warp threads pass from theback of the loom through the shafts then the reed.

SHAFTS
The warp threads are held on shafts which lift and lower in a specific sequence.

WEFT
The rapiers insert each weft thread across the width of the loom through the ‘shed’ which is the space created by the shafts lifting the warp threads. The reed then pushes the weft firmly into place.

TAKE UP MOTION
The woven cloth moves forward and wraps onto a beam at the front of the loom.

THE DROPPERS
The Droppers at the back of the loom balance on the warp threads and if a thread breaks the droppers will alert the weaver.

WARNING LIGHTS
WEFT stopped YELLOW light | WARP broken BLUE light | MACHINE breakdown RED light | END of piece WHITE light.

Darning

IN THE LOOM
The first 30 cms of every order produced is checked and approved before weaving progresses. Our darners ensure that the pattern, the colours and the weave (the construction of the cloth) is correct. A facemark is inserted to indicate the face of the cloth.

INSPECTION
Everything which Lochcarron weave is inspected then any faults are mended. This is called darning.

DARNING
Broken threads are mended, knots are pulled to the back, and in scarves, opened and threaded into the woven construction. We darn at this stage when the construction is quite open and before the cloth is finished.

Finishing

PURLING
This is the process of creating roped / twisted fringes on scarves or rugs. Purling is done before the washing process as this binds the fringes together.

SCOURING
Everything is washed in a 35˚C soap solution to remove the natural lanolin (oils) in the yarn. Speed and timing varies according to the fabric quality being processed.

MILLING
A vigorous wash combining hot water and movement to close up the fabric structure making it more dense. This is a similar process to felting.

TENTERING
The fabric is stretched out and held taught on small metal tenterhooks, this establishes the usable width of the cloth and is part of the drying process “to be on tenterhooks”.

DECATING
This is a final heat treatment which stabilises the fabric and minimises movement during garment manufacture.

BRUSHING
This process uses natural teasles or metal teeth to draw the fibres and create a directional pile on the surface of the cloth. Lambswool, cashmere and mohair are often brushed.

Textile Heritage

BORDER TEXTILES
There is a rich textile heritage in the Scottish Borders which is also very diverse. From sorting to spinning, weaving to knitting finishing, and garment making sadly only a few companies remain today.

THE MILL
Selkirk has a strong tradition of spinning and weaving with many once-famous names. Gardiner of Selkirk, Claridge Malcolm Campbell, Heather Mills amongst many others.

MILL WORKERS
Families worked side by side in the textile mills. School leavers would start in the mills and often work their whole life to retirement in the same mill.
